APM光流传感器解析

libraries/AP_OpticalFlow/AP_OpticalFlow.cpp

主要定义了init(), handle_msp(), update(), start_calibration()等几个函数

init()

主要用于接收光流传感器的类型并定义backend, backend是libraries/AP_OpticalFlow/AP_OpticalFlow_Backend.h中定义的OpticalFlow_backend基类对象, 派生出了PX4Flow, MAVLINK等几个具体传感器类型的派生类, 每个派生中重载了这个类的update(), handle_msg()函数, 分别用于获取光流数据和更新

update()

函数中主要调用了backend->update()的函数, 之后_calibrator->update()校准函数, _calibrator定义于start_calibration()中

if (_calibrator != nullptr) {
    if (_calibrator->update()) {
        // apply new calibration values
        const Vector2f new_scaling = _calibrator->get_scalars();
        const float flow_scalerx_as_multiplier = (1.0 + (_flowScalerX * 0.001)) * new_scaling.x;
        const float flow_scalery_as_multiplier = (1.0 + (_flowScalerY * 0.001)) * new_scaling.y;
        _flowScalerX.set_and_save_ifchanged((flow_scalerx_as_multiplier - 1.0) * 1000.0);
        _flowScalerY.set_and_save_ifchanged((flow_scalery_as_multiplier - 1.0) * 1000.0);
        _flowScalerX.notify();
        _flowScalerY.notify();
        GCS_SEND_TEXT(MAV_SEVERITY_INFO, "FlowCal: FLOW_FXSCALER=%d, FLOW_FYSCALER=%d", (int)_flowScalerX, (int)_flowScalerY);
    }
}

_flowScalerX, _flowScalerY是地面站设置中的缩放参数. 这段代码用于更新缩放参数并发送给GCS

start_calibration()

if (_calibrator == nullptr) {
    _calibrator = new AP_OpticalFlow_Calibrator();
    if (_calibrator == nullptr) {
        GCS_SEND_TEXT(MAV_SEVERITY_CRITICAL, "FlowCal: failed to start");
        return;
    }
}
if (_calibrator != nullptr) {
    _calibrator->start();
}

用于给_calibrator赋值

libraries/AP_OpticalFlow/AP_OpticalFlow_MAV.cpp

主要派生了OpticalFlow_backend类, 重载了获取数据和更新用的handle_msg() update()函数, 新增了几个用于计算的变量

handle_msg()

mavlink_msg_optical_flow_decode(&msg, &packet);
latest_frame_us = AP_HAL::micros64();
flow_sum.x += packet.flow_x;
flow_sum.y += packet.flow_y;
quality_sum += packet.quality;
count++;

从飞控读取数据后将这段时间的光流数据累加起来, 后续update时用的光流速度实际上是i这段时间的平均值

update()

if (gyro_sum_count < 1000) {
        const Vector3f& gyro = AP::ahrs().get_gyro();
        gyro_sum.x += gyro.x;
        gyro_sum.y += gyro.y;
        gyro_sum_count++;
}
if (is_positive(dt) && (dt < OPTFLOW_MAV_TIMEOUT_SEC)) {
    // calculate flow values
    const float flow_scale_factor_x = 1.0f + 0.001f * _flowScaler().x;
    const float flow_scale_factor_y = 1.0f + 0.001f * _flowScaler().y;
    // copy flow rates to state structure
    state.flowRate = { ((float)flow_sum.x / count) * flow_scale_factor_x * dt,
                       ((float)flow_sum.y / count) * flow_scale_factor_y * dt };
    // copy average body rate to state structure
    state.bodyRate = { gyro_sum.x / gyro_sum_count, gyro_sum.y / gyro_sum_count };
    // we only apply yaw to flowRate as body rate comes from AHRS
    _applyYaw(state.flowRate);
} else {
    // first frame received in some time so cannot calculate flow values
    state.flowRate.zero();
    state.bodyRate.zero();
}

首先读取了imu的数据然后也做了平均数, 光流中的flowRate就是光流速度平均值乘以缩放系数, bodyRate是imu的平均值

libraries/AP_OpticalFlow/AP_OpticalFlow_Calibrator.cpp

主要用于计算最佳的缩放比例

struct sample_t {
        float flow_rate;	// 光流速度
        float body_rate;	// imu速度
        float los_pred;	//ekf估计的在车辆运动方向的光流速度的分量
    };

update()

if (_cal_state == CalState::RUNNING) {
    uint32_t now_ms = AP_HAL::millis();
    uint32_t timestamp_ms;
    Vector2f flow_rate, body_rate, los_pred;
    if (AP::ahrs().getOptFlowSample(timestamp_ms, flow_rate, body_rate, los_pred)) {
        add_sample(timestamp_ms, flow_rate, body_rate, los_pred);
        // while collecting samples display percentage complete
        if (now_ms - _last_report_ms > AP_OPTICALFLOW_CAL_STATUSINTERVAL_SEC * 1000UL) {
            _last_report_ms = now_ms;
            GCS_SEND_TEXT(MAV_SEVERITY_INFO, "%s x:%d%% y:%d%%",
                            prefix_str,
                            (int)((_cal_data[0].num_samples * 100.0 / AP_OPTICALFLOW_CAL_MAX_SAMPLES)),
                            (int)((_cal_data[1].num_samples * 100.0 / AP_OPTICALFLOW_CAL_MAX_SAMPLES)));
        }
        // advance state once sample buffers are full
        if (sample_buffers_full()) {
            _cal_state = CalState::READY_TO_CALIBRATE;
            GCS_SEND_TEXT(MAV_SEVERITY_INFO, "%s samples collected", prefix_str);
        }
    }
    // check for timeout
    if (now_ms - _start_time_ms > AP_OPTICALFLOW_CAL_TIMEOUT_SEC * 1000UL) {
        GCS_SEND_TEXT(MAV_SEVERITY_INFO, "%s timeout", prefix_str);
        _cal_state = CalState::FAILED;
    }
}
// start calibration
if (_cal_state == CalState::READY_TO_CALIBRATE) {
    // run calibration and mark failure or success
    if (run_calibration()) {
        _cal_state = CalState::SUCCESS;
        return true;
    } else {
        _cal_state = CalState::FAILED;
    }
}

先从AHRS中获取时间辍, 光流的速度和机体imu的速度, 然后运行run_calibration()进行校准

run_calibration()

// calculate total absolute residual from all samples
float total_abs_residual = 0;
for (uint8_t i = 0; i < num_samples; i++) {
    const sample_t& samplei = _cal_data[axis].samples[i];
    total_abs_residual += fabsf(calc_sample_residual(samplei, 1.0));
}
// 此时计算的是系数为1, 得到的也就是实际上的光流速度


// 先计算残差和
// 如果残差和为零的话就返回1, 说明校准成功
// for each sample calculate the residual and scalar that best reduces the residual
float best_scalar_total = 0;
for (uint8_t i = 0; i < num_samples; i++) {
    float sample_best_scalar;
    const sample_t& samplei = _cal_data[axis].samples[i];
    if (!calc_sample_best_scalar(samplei, sample_best_scalar)) {
        // failed to find the best scalar for a single sample
        // this should never happen because of checks when capturing samples
        GCS_SEND_TEXT(MAV_SEVERITY_INFO, "%s failed because of zero flow rate", prefix_str);
        INTERNAL_ERROR(AP_InternalError::error_t::flow_of_control);
        return false;
    }
    const float sample_residual = calc_sample_residual(samplei, 1.0);
    best_scalar_total += sample_best_scalar * fabsf(sample_residual) / total_abs_residual;
	// 计算的是光流补偿量除以光流速度的平均值, 即系数的平均值
}
// 最佳残差时的系数, 判断光流速度是否存在零, 如果存在零的话就返回false
// 当计算出的最佳缩放系数的均方残差, 当均方小于系数为1计算出的均方残差时返回true (不太理解, 只要系数小于1的话均方肯定也是比他小的呀)
// 返回的缩放系数为best_scalar_total

calc_sample_residual()

float AP_OpticalFlow_Calibrator::calc_sample_residual(const sample_t& sample, float scalar) const
{
    return (sample.body_rate + ((sample.flow_rate * scalar) - sample.los_pred));
}

计算的残差为$imu速度+(光流速度*缩放系数-EKF估计的光流速度在车辆运动方向的分量)$, (等于0时说明系数最佳)

calc_sample_best_scalar()

{
    // if sample's flow_rate is zero scalar has no effect
    // this should never happen because samples should have been checked before being added
    if (is_zero(sample.flow_rate)) {
        return false;
    }
    best_scalar = (sample.los_pred - sample.body_rate) / sample.flow_rate;
    return true;
}

$最佳系数=(EKF估计的光流速度在运动方向的分量-imu速度)/光流速度$
